Swift Group 2009 Charisma - Doorscreen; Heki-2 Roof Light (Seitz); Roof Lights; Windows

Fitted equipment
91
DOORSCREEN
When drawing or releasing the doorscreen,
care should be taken not to let it spring back
freely, this may result in damage to the screen
or its fittings.
Always pull the doorscreen close to the centre. It
is not advisable to pull close to the top or bottom
as this will cause snagging and uneven running.
Caution: When opening or releasing the
doorscreen, care must be taken to avoid
trapping fingers.
Do not allow the doorscreen to slam open.
The door flynet operates independently of the
door by sliding across the door threshold.
ROOF LIGHTS
When opening the roof lights, care must be
taken to release the locking mechanism as the
unit is raised.
Rooflightsmustbefullyclosedwhentowing.
Rooflightsprovide12,500mm2ofxed
ventilation each.
WINDOWS
To open press the knobs in the middle of the
catches and turn through 90°. Swivel the pane
open as required.
To close the window, open the window as far
as possible and slowly close again, turn the
catches through 90° to close.
All opening windows have two catch positions.
The first position is for ventilation the second
seals the window from ventilation and rain.
HEKI-2 ROOF LIGHT (SEITZ)
The lift/tilt roof light can be set in 3 positions by
means of pneumatic springs.
Position1liftsthepane12mmwithoutallowing
rain to enter the caravan.
Position2setsthepanetoa150mmopening
and locks with a bar.
Position3opensthepanethrough55°.
A fully adjustable flyscreen and black-out
screen are built into the inner frame. The
flyscreen can be drawn independently and the
black-out screen is variable for partial or full
black-out.
Forced ventilation functions via a brush lined
duct instead of a ventilated pane.
A cover hood can be fitted for winter protection.
Heki-2rooflightsprovide13,200mm
2
of
fixed ventilation.
