Fitted equipment
89
Lower single beds assembly (Figs. A & B)
1. Unrollbedslatbundleandplacebetween
the recess in both seats.
2. Arrange seat cushions as appropriate.
Double bed assembly (Fig. C)
1. Gripfrontofslattedbedandwalk
backwards until bed is fully extended.
2. Arrange seat cushions as appropriate.
Pullman bunks
1. Releasecatches,oneatatime.
2. Releasepressstudsonthebedboard.
3. Grasp the bunk as shown and pull carefully
in direction of arrows.
4. Thebunkisdesignedtoautomatically
move into the correct position.
5. Whereabedboardistted,unfoldandmake
sure it is secured by press studs when lifted
into position. (The bed board is required to
protect both the occupant and the window
from damage during use of the bunk.)
6. Locate safety boards.
7. Arrange seat cushions as appropriate.
Bunks are designed to carry a child to a
maximumof70kg(11stone)
