Swift MAJOR MJ70-190 - MJ70-410 FM Body

MJ70-410FM Body
Item Part No. Description Qty
1 3000T-AFBGA A' FRAME BUFFER 1
2 MJ70-270-FMGF-BD FLAP GUARD BODY (270) 1
3 MJ70-270-FMGF03 GUARD TUBE 1
4 MJ70-320-STRP01 SWIFT CHAIN SLING 1
5 MJ70-CW-SW20 SWIFT CASTOR (FRONT) 2
6 SW-270-BDGA MJ70-270 BODY 1
7 SW-270-LM20 LINKAGE MOUNT (FRONT) 2
8 3000T-AF-01 3000T A-FRAME 1
9 SW-270-CV01 MJ70-270 BODY COVER 1
10 V600810ENC12RB2 V60 SHEARBOLT / OR 1
11 111044 DIA 26-30mm INSERT 2
12 190.000.545 PTO GUARD (EXTENDED OVAL) 1
13 81 CAT 2 PIN DIA 25.4x110mm 1
14 9162 CAT 2 PIN DIA 28.5x113mm 2
15 AN099/10 LINCH PIN DIA 9.5 3
16 FWM20 M20 FLAT WASHER 4
17 M12x50SZP M12x50 SET BOLT 4
18 M20 M20 NYLOC NUT 1
19 M20x120BZP M20x120 BOLT 1
20 S4444 DIA 1 3/8"x2 1/8"x7/8" COLLAR 2
21 T27A267006 6 SPLINE 'T' BOX RATIO 1.1 1
www.major-equipment.com
54
11
20
5
3
6
20
11
5
8
4
9
21
10
12
1
2
18
16
7
14
15
19
16
17
13
