Swift MAJOR MJ70-190 User Manual

MJ70 Blades
Item Part No. Description Qty
1 BLD-25025-AC BLADE 250xDia 25 (Anti-Clk) 2
2 BLDB-294-25-FXD BLADE BACK (294 CTR 25 deg) 1
3 BLDB-315-25 BLADE BACK (315 CTR 25 deg) 1
4 DF-BMP J205 G/BOX BLADE MOUNT 1
5 BLD-25025H-WSR4 4xDIA 26 BLADE WASHER 4
6 12T-BBS BLADE BACK SPACER 4
7 84RM-BSB BLADE SPACER BUSH 4
8 BB25-16-32 BLADE BUSH 2
9 1/2F 1/2" FINE NYLOC NUT 4
10 12x3FSKS 1/2"x3" FINE SOCKET HEAD 12.9 4
11 DSW34 DISC SPRING 34x16.3 x2 4
12 M10 M10 NYLOC NUT 2
13 M10x25SKBH
M10x25 SOCKET BUTTON HEAD
10.9 2
14 M16 M16 NYLOC NUT 2
15 M16x60BZP M16x60 BOLT 2
Item Part No. Description Qty
1 BLD-25025-C BLADE 250xDia 25 (Clk) 2
2 BLDB-294-25-FXD BLADE BACK (294 CTR 25 deg) 1
3 BLDB-315-25 BLADE BACK (315 CTR 25 deg) 1
4 DF-BMP J205 G/BOX BLADE MOUNT 1
5 BLD-25025H-WSR4 4xDIA 26 BLADE WASHER 4
6 12T-BBS BLADE BACK SPACER 4
7 84RM-BSB BLADE SPACER BUSH 4
8 BB25-16-32 BLADE BUSH 2
9 1/2F 1/2" FINE NYLOC NUT 4
10 12x3FSKS 1/2"x3" FINE SOCKET HEAD 12.9 4
11 DSW34 DISC SPRING 34x16.3 x2 4
12 M10 M10 NYLOC NUT 2
13 M10x25SKBH M10x25 SOCKET BUTTON HEAD 10.9 2
14 M16 M16 NYLOC NUT 2
15 M16x60BZP M16x60 BOLT 2
NOTE:
Items 12 and 13 are supplied
loose with the machine and can
be used to lock the blades.
It’s up to the user whether
the machine will operate with
swinging or rigid blades.
www.major-equipment.com
64
725-BLD-L and 725-BLD-FL 725-BLD-R and 725-BLD-FR
9
4
3
6
10
15
11
8
11
14
1
2
5
7
5
13
12
9
4
3
6
10
15
11
8
11
14
1
2
5
7
5
13
12
