FITTED EQUIPMENT
177
Caravans with external
barbeque point
Models equipped with an external barbeque
point can be used to power any gas appliance
suitable for the gas used in the caravan, at the
working pressure shown on the label in the
barbeque outlet box. Please note when using
the outlet that the fitted regulator will allow a
maximum of 1.5kg per hour of gas to be taken
from the gas bottle. Therefore the consumption
of gas from both the appliances within the
caravan and the appliance connected to the
barbeque point cannot exceed a total of 1.5kg
per hour at any one time. If you are in any
doubt please consult your dealer for advice. To
use point proceed as follows:
When external gas equipment is being
connected, the operating pressure of the gas
supply of 30 or 50 mbar must correspond with
the operating pressure of he equipment that is
being connected (see data plate).
The plug-in connection can only be made if the
quick acting valve is closed. The safety locking
mechanism can be released by sliding back
the coupling sleeve.
The coupling K-valve is being designed such
that the quick acting valve can only be opened
if the connection is being made via the plug-
in connection. The connection is made by
inserting the plug-in connection into the safety
coupling.
This operation can be carried out using one
hand. After uncoupling the equipment, seal off
the valve opening using the protection seal.
Note: The external gas socket is only
suitable for removing gas, not for feeding
gas into the gas system.
! WARNING: Care should be taken when
using the external barbeque point. Never
barbeque next to an awning or tent.
! WARNING: The caravan barbeque point
should only be used as an outlet point for
gas, never connect a gas bottle direct to the
outlet.
EXTERNAL BBQ POINT
