ATTENTION :
Disconnect: A means to disconnect should be located within sight of and readily accessible from the
unit(circuit breaker, fused or un-fused switch). This is common practice on commercial and
residential heat pumps. It prevents remotely-energizing unattended equipment and permits turning off
power at the unit while the unit is being serviced.
6.2 Installation of the display deportee
Photo(1) Photo(2) Photo(3) Photo(4) Photo(5)
- The end with plug connects with the control panel (photo1)
- The other end of the signal wire. (photo2)
- Open the cover of the terminal box and pass through it the cable of the remote screen.(photo3,4)
