Model : Swimmax 07iPS
No.
Part name
No.
Part name
1
Top cover
29
High pressure switch
2
Ambient temp. sensor T5-TH1
30
Discharge pipe
3
Ambient temp. sensor clip
31
4-way valve to exchanger
4
Back grill
32
Low pressure switch
5
Evaporator
33
Main capillary
6
Evaporator temperature sensor T3-TH2
34
Pipe
7
Clip
35
Pipe
8
Sensor holder
36
4 way valve
9
Electric box cover
37
Pipe
10
Top frame
38
Needle valve
11
PCB
39
Titanium heat exchanger
12
Pilar
40
Drainage plug
13
Electric box
41
Water inlet temp. sensor T1-TH6
14
Left panel
42
Exchanger temperature sensor clip
15
Isolation panel
43
Right panel
16
Reactor
44
Terminal board
17
Compressor
45
Pressure gauge
18
Fan motor support
46
Clip
19
Base tray
47
Terminal board cover
20
Fan motor
48
5-ways terminal block
21
Fan blade
49
Water outlet temp. sensor T2-TH5
22
Front panel
50
Red rubber ring
23
Waterproof controller box
51
Evaporator pipe
24
Controller box cover
52
Distribution piping
25
Controller
53
Blue rubber ring
26
Front grill
54
Water connection sets
27
Discharge temp. sensor T6-TH3
55
Red rubber ring
28
Gas return piping
56
WIFI Module
