Spare parts list: Swimmax 25iPS
No.
Part Name
No.
Part Name
1
Top cover
32
Pressure gauge
2
Back grill
33
Clip
3
Evaporator
34
Terminal board cover
4
Pillar
35
5-ways terminal block
5
Top frame
36
Right panel
6
Isolation panel
37
Water outlet temp. sensor T2-TH5
7
Reactor
38
Water flow switch
8
Fan motor support
39
High pressure switch
9
Fan motor
40
Discharge temp. sensor T6-TH3
10
Fan blade
41
Clip
11
Left panel
42
Low pressure switch
12
Front panel
43
Gas return piping
13
Back grill
44
Discharge pipe
14
Waterproof controller box
45
Sensor holder
15
Pipe
46
Pipe
16
Controller box cover
47
Evaporator pipe
17
Electric box cover
48
Distribution piping
18
Base tray
49
Evaporator temperature sensor
T3-TH2
19
Controller
50
Back panel
20
Compressor
51
Blue rubber ring
21
PCB
52
Water connection sets
22
Pipe
53
Red rubber ring
23
Liquid Reservoir
54
Pipe
24
Wifi module
55
4 way valve
25
Electric box
56
EEV
26
Filter
57
Pipe
27
Drainage plug
58
Pipe
28
Exchanger temperature sensor
clip
59
Ambient temp. sensor T5-TH1
29
Water inlet temp. sensor T1-TH6
60
Ambient temp. sensor clip
30
Terminal board
61
Needle valve
31
Titanium heat exchanger
