Spare parts list: Swimmax 30iPS
No.
Part Name
No.
Part Name
1
Top cover
40
Evaporator pipe
2
Ambient temp. sensor T5-TH1
41
Back panel
3
Ambient temp. sensor clip
42
Needle valve
4
Back grill
43
Gas return piping
5
Evaporator
44
Low pressure switch
6
Evaporator temperature sensor T3-TH2
45
Pipe
7
Clip
46
Discharge pipe
8
Sensor holder
47
Pipe
9
Distribution piping
48
4 way valve
10
Isolation panel
49
High pressure switch
11
Reactor
50
Discharge temp. sensor T6-TH3
12
Pillar
51
Pipe
13
Top frame
52
Pipe
14
Fan motor support
53
Pipe
15
Front panel support
54
EEV
16
Fan motor
55
Filter
17
Fan blade
56
Pipe
18
Fan motor assemble
57
Water flow switch
19
Waterproof controller box
58
Water outlet temp. sensor T2-TH5
20
Left panel
59
Exchanger temperature sensor clip
21
Front grill
60
Titanium heat exchanger
22
Front panel
61
Water connection sets
23
Controller box cover
62
Blue rubber ring
24
Controller
63
Connector sealing ring
25
Compressor
64
Water inlet temp. sensor T1-TH6
26
Compressor damping feet
65
Drainage plug
27
Liquid Reservoir
66
Red rubber ring
28
Compressor heating resistor
67
Sealing ring
29
Base tray
68
Electric box cover
30
Handler panel
69
Driver board
31
Terminal board support
70
Relay
32
Right panel
71
Filter board
33
3-ways power terminal block
72
Magnetic ring
34
Pressure gauge
73
PCB
35
Clip
74
Electric box
36
Terminal board support
75
Magnetic ring
37
3-ways terminal block
76
Wifi module
38
Terminal board cover
77
Scale panel
39
Rubber block
