Installation instructions
9. Connecting the ceiling cover
- Lift the ceiling cover over the hanging bracket.
- Rotate the ceiling cover and tighten the screws.
Ceiling cover screws
Slot
Ball-joint
7. Hanging the fan
- Carefully lift the fan motor.
- Place the ball-joint in the hanging bracket, so that the groove is located in the slot. The down rod
should not rotate if this is done correctly.
Attention! To ensure smooth operation of the fan it is important to securely fasten all the screws intended for hanging it.
8. Connecting the ceiling fan to the electricity supply
After the ceiling fan is properly hung, connect the terminal plug connector (male to female).
Connector terminal plug
9
SWING MARBLE
Fan Installation Instructions | Version 1.22
