1 [PITCHBEND]
Pitch bend wheel to vary the pitch when playing.
2 [MODULATION]
Modulation wheel.
3 [OCTAVE]
Buttons to octave / transpose the keyboard.
4 Display.
5
Function / select buttons, see
Ä
‘Function / select buttons [5]’ on page 11.
6 [E1] … [E8]
Rotary encoder
7 [S1] … [S8]
Fader with LED chain display.
8 [A1 | B1] … [A8 | B8]
Mute / solo buttons.
9 [TRACK]
Button for the simultaneous shifting of all encoders and faders.
10 [MASTER]
Master fader.
11 [P1] … [P8] ([P16])
Programmable trigger pads.
Top view
Connections and operating elements
MIDI keyboard
10
