4
Contents
Maintenance ......................................................................................................................................... 3
Contents ............................................................................................................................................... 4
Operation Instructions ........................................................................................................................... 5
·Front Panel ................................................................................................................................... 5
·Back Panel ................................................................................................................................... 6
·OSD .............................................................................................................................................. 6
·Zoom-in and mapping ................................................................................................................... 7
Main menu ............................................................................................................................................ 9
Specification........................................................................................................................................ 17
Trouble-shooting ................................................................................................................................. 18
Packing list
Standard Package:
1. User Manual
2. Warranty Card
3. LCD protective film
4. Power cable
Introduction
M-1073H adopts TFT LCD panel, with resolution 1920×1200 and wide viewing angle H160°⁄V160°. It
supports 2 x 3GSDI (Level A/B), 1 x HDMI2.0 (4K display) input. It also supports 1x 3GSDI, 1 x HDMI
and 1 x analog audio loop through output.
Features:
 Support HDMI 4K display
 Camera Log conversion
 Support 3DLut cube
 Support multiple Aspect Ratio and scan modes
 Support multiple Marker selection (Marker, Safety Area)
 Powerful audio and video analysis functions
 Support multiple functions user-defined (Source ID, function keys)
 USB firmware upgrade
