3 Operating Elements
The buttons in this operating manual are subsequently depicted
with a uniform contour. Therefore, slight deviations in the appear-
ance of the symbols on the walkie−talkie buttons compared to those
depicted here are possible.
Handset
1 Display
2 Headset connection socket
3 Charging cable socket
4 On / Off
5 Menu
6 Microphone
7 Volume / Setting +
8 Loudspeaker
9 Volume / Setting −
10 Transmit ringing tones
11 PTT − Talk button
12 Antenna
Display
1 CTCSS code
2 Channel
3 Time
4 Receiving
5 Volume control
6 VOX mode
7 Dual−channel
monitoring
8 Key lock
9 Battery capacity
10 Transmit
11 Channel search
