SWorkz S35-4e EVO - Page 18

18
23
22
BAG
E3
BAG
E3
338080
116006R
101018
228001DG (#17 #18)
340016
210046
340016
228001DG (#17 #18)
330124
104010
Left
Right
330124
Pin M3.0x16.8mm
x2
104010
M5x4mm Set Screw (Flat Bottom)
x2
106009
103001
106009
M3x25mm Hex Socket OH/TP Screw
x4
103001
M3 Nut Lock
x4
101018
SHIM 13x16x0.2mm
x2
116006R
228002-1
PRO TIP:
The new multi adjustable rear hub can be set
to a wider or a narrow conguration using the
inserts 228001DG (#17 #18)
116006R
Ball Bearing 8x16x5mm (Red Rubber Case)
x4
330117A
330117A
OPTION:
SWC-218007A
S35 Series Evolution-CVA Drive Shaft
Set 92.5mm (1 Set)
SWC-218007D
S35 Series Advance-CVD Drive Shaft
Set 92.5mm (1 Set)
OPTION:
SW-338075
S35-4 Series T7
Aluminum Rear
Wheel Hub With
BB Insert (R=L)
(1PC)
