SY Electronics SY-MUHD-44 User Manual

SY-MUHD-44 & SY-MUHD-88
www.sy.co.uk 8
IP Set-Up Commands
Set the Host IP address of the matrix switcher
(Default: 192.168.001.239)
>@WIPH xxx.xxx.xxx.xxx¿
Set the subnet mask
(Default: 255.255.255.000)
>@WIPN xxx.xxx.xxx.xxx¿
Set the Router IP address
(Default: 192.168.001.001)
>@WIPR xxx.xxx.xxx.xxx¿
Set the TCP/IP port number
(Default: 23)
>@WIPH zzzzz¿
Set DHCP on
>@WIPDP ON¿
Set DHCP off
>@WIPDP OFF¿
Get Status Information
Output a report giving the current status of the matrix switcher
(2)
>@RSTA¿
Read the input connection status
(4)
>@R8001¿
Read the output connection status
(4)
>@R8002¿
Read input HDCP status
(4)
>@R8003¿
Read output HDCP status
(4)
>@R8004¿
Read output channel settings
(4)
>@R8006¿
Read output On/Off states
(4)
>@R8007¿
Read External (de-embedded) audio status
(4)
>@R8008¿
Read input EDID setting
(4)
>@R8009¿
Read all network settings
(5)
>@R8012¿
Read cascade mode status
(4)
>@R8017¿
Other Commands
Power off the matrix switcher (enter standby mode)
>@WSPF¿
Power off the matrix switcher (exit standby mode)
>@WSPN¿
Help, list all available commands
(2)
>@RH¿
Reset to factory defaults
>@WSDF¿
Notes:
(1) This command generate a large report giving detailed information about the current status of
the matrix switcher.
(2) This command lists all the commands that the matrix switcher supports.
(3) These EDID commands output an ASCII data block that lists the values of the requested EDID
data values in hexadecimal notation.
(4) These commands respond with a short message, usually one line, giving the requested
information.
(5) The IP status command will respond with all the current IP settings: Host IP address, Subnet
mask, Router IP address, TCP/IP port number and the DHCP setting.
