Sylvac S Mike PRO - Page 4

4
12 6
3
9
4 5
8
7
1. Measuring spindle
2. Anvil
3. Isolation plate
4. MODE button
5. SET button
6. Rotating thimble
7. Proximity connector
1)
8. Battery cover
9. Battery low indicator
10. Hold indicator
11. Data send indicator
12. Locking indicator
13. Bluetooth
®
indicator
2)
12
13
10
11
