2. Control location
MODE：BS05W SERIES
Head light
Front brake lever
Rear brake lever
Tail light
Helmet hook
Fuel tank cap
Engine number
Storage box
Muffler
Fuses / C.D.I. /
Eng. Oil tank cap
Light / Starter switch
High & Low beam /
Turn signal / Horn switch
Air cleaner
Front turn signal
Ignition switch
Rear turn signal
Seat lock
Frame number

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sym JET 100 series and is the answer not in the manual?

Sym JET 100 series Specifications

General IconGeneral
Fuel SystemCarburetor
Front SuspensionTelescopic Fork
Rear BrakeDrum
Cooling SystemAir-cooled
TransmissionAutomatic
Engine Type4-Stroke
