12. BODY COVER
12-4
Body Cover
1. Removal:
y Remove 4 bolts from rear carrier, and
then remove rear carrier.
y Remove 1 screw and 2 nuts and 1bolt
from luggage box, and then remove
luggage box.
z Remove 3 screws from the tail cover,.and
then remove the tail cover.
Remove 2 screws astern of the body cover
Bolts
Screws
