2. Service Maintenance Information
2-3
Air Cleaner
Remove the mounting screw from the air
cleaner cover
Remove the air cleaner cover
Remove the air cleaner element
Clean the element with non-flammable or
high-flash point solvent and then squeeze it for
dry.
Caution
Never use gasoline or acid organized solvent to
clean the element.
Soap the element into cleaning engine oil and
then squeeze it out. Install the element onto the
element seat and then install the air cleaner
cover.
Limit to use SAE 20 JASO FC class engine oil;
otherwise, SYM is no responsible for the
warranty.
Recommended engine oil: MAX-2 serial oils.
Fuel Lines
Remove the luggage box.
Check fuel lines and replace damaged lines if
found.
Install the luggage box.
To Next Page
