8. "V" Type Belt Drive System/Kick-Starter
8-1
Maintenance Information·····················8-3
Trouble Shooting ·································8-3
Left Crankcase Cover ··························8-4
Reassembly Of Kick Starter ················8-5
Installation Of The Left Crankcase Cover
·······························································8-5
Drive Belt··············································8-6
Movable Driven Pulley·························8-7
Clutch/Driven Pulley····························8-11
8
5.5~6.5
kg
f
-
m
3.5~4.5
kg
f
-
m
5.0~6.0
kg
f
-
m
