7
 Voltage:
Display average voltage of battery.
Clock:
Show time (Display range: 0:00 ~ 23:59 (hh:mm))
 Fuel Meter:
Display the fuel level in the tank.
Fuel warning level displays six bars and tapered from top to bottom.
 EFI indicator:
It displays the condition of the EFI system. If there is problem in the EFI system, the warning
indicator will blink or light up all the time.
 Engine oil change warning light:
It is used to indicate the oil exchange time, with lights when the vehicle was driven about 1,000km
for the first time, and after every 2,000km, the indicator light will light up, warn the users to replace
the oil.
After finish oil change, put the main switch in “ON”, short press "SET" button two times in “OIL”
mode, then the indicator light will go out.
 Low fuel load warning light:
When there is a little fuel inside the tank, the warning lamp will be on.
 Button Function:
(When not specified, long press is 2 seconds, short press is 0.5 seconds).
Long press the “MODE” button and “SET” button at the same time to switch between mile and km,
and it should be saved when the machine is turned on or off.
 Clock Setting:
In time display mode, when the scooter is stationary, long press the "MODE" button more than 2
seconds to enter the time setting, at this time press “MODE” button 0.5 second, it can switching
over setting mode (Hour → minutes tens digit → minute unit digits).
Short press "SET" button once, figure add 1.
(The clock setting state will automatically exit the setting mode without any operation for 30 second.)
Short press “MODE”
Press “SET” to adjust
HOUR
MINUTE (tens digits)
MINUTE (unit digits)
Return to normal mode
Short press “MODE”
Short press “MODE”
Press “SET” to adjust
Press “SET” to adjust
Long press “SET”
Short press “MODE”
Short press “SET”
two times
Short press “MODE”
Short press
“ MODE”
TOTAL
TRIP
Clear TRIP mileage value
OIL
Clear OIL mileage value
