3
2.CONTROL LOCATION
MODEL: ORBIT III 50 125XE05W1-EU/IT/NL XE12W1-EU
Fuel tank cap
Exhaust Muffler
High &Low beam/Passing/
Turn signal/Horn switch
Front brake level
Tail light
Battery
Air Cleaner
Oil level
Front turn signal
light
Helmet hook
Storage box
Main stand
Ignition switch
Front /Rear brake level
Engine start
control switch
Side stand
Front light /
Position light
Rear turn
signal light
Engine number
Frame number
