2.5 Spindle tube oiling
1. Press down on the spindle rubber part and use
a wrench to unscrew the set screw and then
unscrew the propeller.
2.Remove the motor by unscrewing the four screws on both sides of the motor.
6. Twist the cabin knob to the left/right until it snaps tight
EN
For waterproof reasons, the hatch cover is designed to fit tightly and must be removed or
closed with force correctly.
