8.0 Specifications/Characteristics
The following table presents the specifications for the 58536A GPS Distribution Amplifier.
Table 1. 58536A Specifications/Characteristics
Frequency Bandwidth (3 dB)
1575.42 MHz
±
10 MHz
Gain (antenna to output)
0 dB
±
3 dB (typical) @ 1575.42 MHz (L1)
Noise Figure 5 dB (typical) @ 25°C
VSWR Input: 1.2:1 (typical) @ L1
Output: 1.6:1 (typical) @ L1
Isolation
26 dB (typical) @ 1575.42 MHz (L1)
50 dB (typical) @ f
L1
40 MHz
50 dB (typical) @ f
L1
+
40 MHz
DC Power
Operating voltage
*
(see Caution
below)
Damage level
Operating current
+
4.5 Vdc to
+
13 Vdc
>
18 Vdc, either polarity
23 mA to 48 mA (depending on operating voltage)
AC Input Level (antenna signal)
Impedance
Maximum operating
Damage level
50
, nominal
25 dBm
+
17 dBm @ L1
AC (output ports)
Impedance
50
, nominal
Connectors 5 Type-N Jacks
Operating Environment
35°C to
+
75°C
Weight 0.5 kg
Dimensions (including connectors) 95 mm W x 130 mm L x 35 mm H
Mounting Holes 2 holes, 4.4 mm diameter
Caution:
*Operating voltage is passed through to the antenna. The 58532A antenna
operates on
+
5 Vdc nominal. Applying greater than
+
5 Vdc nominal may damage the
58532A.
