SymNet Express Cobra Family
Introduction•Overview
SymNet Express hardware configurations:
Analog
In
Analog
Out
CobraNet
In/Out
Analog
Control
Inputs
Relay
Output
Open
Collector
Outputs
RS-232
Host/
Control
Port
Ethernet
Control
Port
RS-485
Control
Port
Redundant
Power
Supply *
Express 12x4 Cobra 12 4 16/16 2 1 2 yes yes yes optional
Express 4x12 Cobra 4 12 16/16 2 1 2 yes yes yes optional
Express 8x8 Cobra 8 8 16/16 2 1 2 yes yes yes optional
Express 4x4 Cobra 4 4 16/16 2 1 2 yes yes yes optional
* Symetrix model PS-7, sold separately.
Introduction
SymNet™ is a scalable DSP platform configured by SymNet
Designer software and made by Symetrix. Installed in
Convention Centers, Sports Arenas, Houses of Worship
and many other venues throughout the world, consultants,
integrators and end-users rely on the robust stability of the
SymNet platform.
SymNet is an open architecture system. This means DSP
modules (EQ, compression, etc.) are placed into the
design and connected using standard drag-and-drop
methods. Various SymNet hardware can be chained
together to provide a custom audio solution for the client.
SymNet’s main advantage can be summed up in one word:
“Options”. Options for DSP processing, options for audio
routing and options for control.
Note: Express Cobra devices require SymNet Designer 5.0
or later.
Overview
SymNet Express Cobraisafamilyof19”rack-mountable
digital signal processors (DSP) that are setup and controlled
by SymNet Designer software. Ideal for audio applications
such as churches, conference rooms, courtrooms, night
clubs and many others. ARC Wall panels easily integrate
with Express hardware and provide simple user control of
the system.
There are four analog I/O options available for the
Express line: 12x4, 4x12, 8x8, and 4x4. Express devices
employ industry-standard CobraNet
®
technology to share
audio between devices supporting 16 inputs and 16 outputs
of CobraNet audio over Ethernet in addition to the analog
I/O.
Devices are initially configured through the RS-232 port on
the rear panel. This same port is used to connect to external
controlsystemsfromAMX,Crestron,andothers.Once
the system is initially configured, Express devices can be
addressed and controlled over Ethernet.
Any of the ARC Wall Panels can be connected via CAT5
cable to an RJ-45 jack on the rear panel. One channel of
analog audio can be routed to or from the wall panel over
the CAT5 cable for simple paging or monitoring needs.
ExpressalsoincludesanRS-485portforextendingtheARC
and external control capacity.
PERFORMANCE DATA
Item Specifications
Converter Types 24-bit Sigma Delta
Sampling Rate 48kHz,+/-100ppm
Frequency Response +/-0.5dB,20Hz-20kHz
A/D dynamic range >110dB(A-weighted)
D/A dynamic range >110dB(A-weighted)
Total THD+Noise <0.005%@1kHz,-1dBFS
Delay Memory 43 seconds (mono)
Input impedance 6.67kOhms,Balanced
Output impedance 204Ohms,Balanced
Maximum input level +29dBu,with6dBpadengaged,
+23dBuwithoutpad(typical)
Maximum output level +24dBu,100kOhmsor+21dBu,600Ohms(typical)
Mic pre-amp EIN -129dButypical,22-22kHz,A-weighted
Phantom power +48VDC,10mA(perinput)
Input CMR >70dB@60Hz
Channel separation >100dB,inthroughout@1kHz
