10-2 L2200PIN
71 N.U. Not Used
72 I2C OPEN
White Balance Adjustment
Judgement
73 AFT AFT Voltage Input
74 N.U. Not Used
75 AGC AGC Voltage Input
76 PROTECT 3 Power Supply Protection
77 N.U. Not Used
78 FM-SW Switching IF IC VCO
79 P-ON-H Output for P-ON-H
80 N.U. Not Used
Pin
No.
Signal Name Function
