Symphonic ST419E - Parts Lists

20031105 12-1 L2200CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (----------) are
not available.
ST413E
Ref. No. Description Part No.
A1 FRONT CABINET L1300UA 0EM000485
A2 CONTROL PLATE L6300UA 0EM301706
A3 REAR CABINET L6300UA or 0EM101240
REAR CABINET L6300UA or 0EM101248
REAR CABINET L6305UF 0EM000678
A4# RATING LABEL L2200UA ----------
B1 SPRING TENSION B0080B0:EM40808 26WH006
B2 CRT MOUNTING SCREW B0030U1:K42419 8A00083
B3 PCB HOLDER L1300UA 0EM301412
B4 SPEAKER HOLDER L1300UA 0EM406030
B5# LABEL CRITICAL PARTS WARNING
B8007C3:EM41210
----------
CLN551 CRT GND WIRE CRT GND WX1L7720-001
CLN801 WIRE ASSEMBLY WX1L9200-001
DG691# DEGAUSSING COIL F-017 or LLBH00ZTM017
# DEGAUSSING COIL AVDG013 or LLBH00ZWR017
# DEGAUSSING COIL or LLBH00ZTZ017
# DEGAUSSING COIL LLBH00ZTM022 or LLBH00ZTM022
# DEGAUSSING COIL AI-004-00 LLBH00Z5A006
L1 SCREW, P-TIGHT 3X12 BIND HEAD+ GBMP3120
L2 SCREW, P-TIGHT 4X18 BIND HEAD + GBMP4180
PB4# CHASISS NO. LABEL L6300UA ----------
SP801 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
PACKING
S1 CARTON L2200UA 0EM408762
S2 STYRFOAM TOP ASSEMBLY L6000UA 0EM406803
S3 STYRFOAM BOTTOM ASSEMBLY L6000UA 0EM406802
S4 SET SHEET L6000UA:700X1200 0EM407141
S5 HOLD PAD L6000UA 0EM201556
S6 SERIAL NO. LABEL L2200UA ----------
ACCESSORIES
X1# OWNER'S MANUAL(E)/(S) L2300UA:ENGLISH/
SPANISH
0EMN02332
X2 REMOTE CONTROL 130/ERC001/N0108UD or N0108UD
REMOTE CONTROL 130/ERC001/N0132UD N0132UD
X3 DRY BATTERY R6P UM3 or XB0M451GH001
DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY R6P(AR)2PX or XB0M451HU002
DRY BATTERY R6P(AR)2P X ICI XB0M451HU003
X4 SHEET RETURN STOP L6100UA 0EM407076
X5 BAG POLYETHYLENE 235X365XT0.03 0EM408420
X6 ROD ANTENNA L7720UA:NTSC W/COO or 0EMN00673
ROD ANTENNA T5000UA 0EMN01599
Note:
1. V501 (CRT) HAS COUPLE OF SUBSTITUTIONAL PARTS AND EACH PARTS
ALSO HAS MATCHING COMBINATION WITH DY551.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
2. DY551 (DEFLECTION YOKE) HAS MATCHING COMBINATION WITH V501.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
CRT TYPE A
DY55 1# DEFLECTION YOKE KDY3GDA82X or LLBY00ZMS011
# DEFLECTION YOKE LLBY00ZSY005 LLBY00ZSY005
V501# CRT A34AGT13X TCRT190CP036
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE B
DY55 1# DEFLECTION YOKE LLBY00ZSY002 or LLBY00ZSY002
# DEFLECTION YOKE CDY-M1456S or LLBY00ZQS008
# DEFLECTION YOKE KDY3GC734X or LLBY00ZMS006
# DEFLECTION YOKE KDY3GCE83X or LLBY00ZMS027
# DEFLECTION YOKE DSE1493FU(S) LLBY00ZSM008
V501# CRT A34KQW42X TCRT190SM013
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE C
DY55 1# DEFLECTION YOKE KDY3GD591X or LLBY00ZMS005
# DEFLECTION YOKE CDY-M1422F LLBY00ZQS001
V501# CRT A34JLL90X(W) TCRT190QS015
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE D
DY55 1# DEFLECTION YOKE LLBY00ZSY003 or LLBY00ZSY003
# DEFLECTION YOKE KDY3GD592X or LLBY00ZMS004
# DEFLECTION YOKE CDY-M1455F LLBY00ZQS007
V501# CRT A34LRQ90X(VW) TCRT190P7003
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE E
DY55 1# DEFLECTION YOKE LLBY00ZSY002 or LLBY00ZSY002
# DEFLECTION YOKE KDY3GC587X or LLBY00ZMS003
# DEFLECTION YOKE CDY-M1456S or LLBY00ZQS008
# DEFLECTION YOKE KDY3GCE83X LLBY00ZMS027
V501# CRT A34KPU02XX TCRT190GS016
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE F
DY55 1# DEFLECTION YOKE KDY3GCB05X or LLBY00ZMS014
# DEFLECTION YOKE ST14PWRF01 LLBY00ZSAM01
V501# CRT A34LEX10X TCRT190SAM01
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE G
DY55 1# DEFLECTION YOKE LLBY00ZSY002 or LLBY00ZSY002
# DEFLECTION YOKE KDY3GCB82X or LLBY00ZMS018
Ref. No. Description Part No.
