20031105 12-2 L2200CA
ST419E
# DEFLECTION YOKE KDY3GCE83X LLBY00ZMS027
V501# CRT A34JQQ093X TCRT190MS010
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE H
DY5 51# DEFLECTION YOKE KDY3GCE83X or LLBY00ZMS027
# DEFLECTION YOKE LLBY00ZSY002 or LLBY00ZSY002
# DEFLECTION YOKE CDY-M1456S LLBY00ZQS008
V501# CRT A34JXV70X TCRT190THA02
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
Ref. No. Description Part No.
A1 FRONT CABINET L1400UA 0EM000479
A2 CONTROL PLATE L2300UA 0EM302011
A3 REAR CABINET L6400UA or 0EM000683
REAR CABINET L6405UF 0EM000679
A4# RATING LABEL L2300UA ----------
B1 SPRING TENSION B0080B0:EM40808 26WH006
B2 CRT MOUNTING SCREW B0030U1:K42419 8A00083
B3 PCB HOLDER L1400UA 0EM301429
B4 SPEAKER HOLDER L1400UA 0EM406026
B5# LABEL CRITICAL PARTS WARNING
B8007C3:EM41210
----------
B6# DEGAUSS HOLDER L9800UA 0EM404845
B7 AC CORD HOLDER L1400UA 0EM406104
B8 CLOTH L9800UA:95X15XT:0.5 0EM405041
B9 CLOTH(10X30XT1.0) L9814UQ 0EM405137
CLN551 CRT GND WIRE CRT GND WX1L7820-003
CLN801 WIRE ASSEMBLY SPEAKER WIRE(220MM) WX1L7950-001
DG691# DEGAUSSING COIL AVDG176 or LLBH00ZWR050
# DEGAUSSING COIL F-051 or LLBH00ZTM051
# DEGAUSSING COIL AI-012-00 LLBH00Z5A012
L1 SCREW, P-TIGHT 3X12 BIND HEAD+ GBMP3120
L2 SCREW, P-TIGHT 4X18 BIND HEAD + GBMP4180
L3 SCREW TAPPING M4X14 DBU14140
SP801 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
PACKING
S1 CARTON L2300UA 0EM408753
S2 STYRFOAM TOP ASSEMBLY L9814UQ 0EM405094
S3 STYRFOAM B0TTOM ASSEMBLY L6100UA 0EM406813
S4 SET SHEET L1400UA:1000X1500 0EM406680
S5 HOLD PAD L6100UA 0EM406812
S6 SERIAL NO. LABEL L2300UA ----------
ACCESSORIES
X1# OWNER'S MANUAL(E)/(S) L2300UA:ENGLISH/
SPANISH
0EMN02332
X2 REMOTE CONTROL 130/ERC001/N0108UD or N0108UD
REMOTE CONTROL 130/ERC001/N0132UD N0132UD
X3 DRY BATTERY R6P UM3 or XB0M451GH001
DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY R6P(AR)2PX or XB0M451HU002
DRY BATTERY R6P(AR)2P X ICI XB0M451HU003
X4 SHEET RETURN STOP L6100UA 0EM407076
X5 BAG POLYETHYLENE 235X365XT0.03 0EM408420
Ref. No. Description Part No.
Note:
1. V501 (CRT) HAS COUPLE OF SUBSTITUTIONAL PARTS AND EACH PARTS
ALSO HAS MATCHING COMBINATION WITH DY551.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
2. DY551 (DEFLECTION YOKE) HAS MATCHING COMBINATION WITH V501.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
CRT TYPE A
DY55 1# DEFLECTION YOKE KDY3MDA84X or LLBY00ZMS013
# DEFLECTION YOKE LLBY00ZSY006 or LLBY00ZSY006
# DEFLECTION YOKE CDY-M2019F LLBY00ZQS004
V501# CRT A48JLL90X or TCRT190QS009
# CRT A48JLL90X(K) TCRT190QS019
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE B
DY55 1# DEFLECTION YOKE KDY3MCB20X or LLBY00ZMS016
# DEFLECTION YOKE 330P510A37 LLBY00ZTHA01
V501# CRT A48LGS30X TCRT190THA01
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE C
DY55 1# DEFLECTION YOKE DSE-1922FU(T) or LLBY00ZSM007
# DEFLECTION YOKE TMY0301F or LLBY00ZMS017
# DEFLECTION YOKE CDY-M2023F or LLBY00ZQS005
# DEFLECTION YOKE LLBY00ZSY007 LLBY00ZSY007
V501# CRT A48LRH93X(W)D or TCRT190PTD01
# CRT A48LRH93X(W) TCRT190P7002
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE D
DY55 1# DEFLECTION YOKE LLBY00ZSY008 LLBY00ZSY008
V501# CRT A48LVL095X TCRT190MS011
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE E
V501# CRT A48AKH13X01 K TCRT190CP043
CRT TYPE F
DY55 1# DEFLECTION YOKE KDY3MDD74X LLBY00ZMS024
V501# CRT A48AKH13X TCRT190CP044
V501-1 C.P.MAGNET JH225-014 or XM04000BV009
CPM E-225-F01 XM04000ETC01
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
Ref. No. Description Part No.
To Next Page
