20031105 13-2 L2200EL
ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C328 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASTL100
ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C329 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C330 TF CAP. 0.47µF/50V J or CT1J474MS045
FILM CAP. 0.47µF/50V J 122Z317S
C341 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C342 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASTL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL010
C343 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C345 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASTL471
ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C347 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASTL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C349 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASTL471
ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C351 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C352 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C353 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASTL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL010
C362 ELECTROLYTIC CAP. 2.2µF/50V M or CE1JMASTL2R2
ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C551 ELECTROLYTIC CAP. 47µF/35V M or CE1GMASTL470
ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C552 FILM CAP.(P) 0.1µF/50V J or CMA1JJS00104
FILM CAP.(P) 0.1µF/50V J CA1J104MS029
C554 A ELECTROLYTIC CAP. 100µF/35V M or CE1GMASTL101
A ELECTROLYTIC CAP. 100µF/35V M CE1GMASDL101
C554 B ELECTROLYTIC CAP. 470µF/35V M(VR)
or
CE1GMZNTL471
B ELECTROLYTIC CAP. 470µF/35V M or CE1GMZNDL471
B ELECTROLYTIC CAP. 470µF/35V M CE1GMZADL471
C562 ELECTROLYTIC CAP. 2.2µF/50V M LL or CE1JMASLL2R2
ELECTROLYTIC CAP. 2.2µF/50V LL CE1JMASLH2R2
C566 ELECTROLYTIC CAP. 1000µF/25V M or CE1EMZNTL102
ELECTROLYTIC CAP. 1000µF/25V M or CE1EMZPDL102
ELECTROLYTIC CAP. 1000µF/25V M CE1EMZADL102
C568 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASTL100
ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C571# A PP CAP. 0.33µF/250V J or CT2E334MS041
# A P.P. CAP 0.33µF/200V J or CA2D334VC012
# A METALLIZED FILM CAP. 0.33µF/200V J or CT2D334F7001
# A METALLIZED FILM CAP. 0.33µF/200V J CT2D334F7003
C571# B PP CAP. 0.47µF/250V J or CT2E474MS041
# B P.P.CAP 0.47µF/200 J or CA2D474VC012
# B METALLIZED FILM CAP. 0.47µF/200V J CT2D474F7003
C574# ELECTROLYTIC CAP. 4.7µF/250V M or CE2EMASTL4R7
# ELECTROLYTIC CAP. 4.7µF/250V M CE2EMASDL4R7
C577# ELECTROLYTIC CAP. 47µF/35V M or CE1GMASTL470
# ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C578 FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
FILM CAP.(P) 0.01µF/50V J CA1J103MS029
C580# A PP CAP. 0.0082µF/1.6KV J or CT3C822MS039
# A P.P. CAP 0.0082µF/1.6K J or CA3C822VC011
# A METALLIZED FILM CAP. 0.0082µF/1.6KV
J
CT3C822F7004
C580# B PP CAP. 0.01µF/1.6KV J or CT3C103MS039
# B P.P.CAP 0.01µF/1.6KV J or CA3C103VC011
# B METALLIZED FILM CAP. 0.01µF/1.6KV J CT3C103F7004
Ref. No. Mark Description Part No.
C581# B CERAMIC CAP. LB 1000pF/2KV or CA3D102KG004
# B CERAMIC CAP. BN 1000pF/2KV or CCD3DKA0B102
# B CERAMIC CAP. 1000pF/2KV or CA3D102PAN04
# B CERAMIC CAP RB 1000pF/2KV CA3D102TE006
C584# ELECTROLYTIC CAP. 1µF/160V M or CE2CMASTL1R0
# ELECTROLYTIC CAP. 1µF/160V M CE2CMASDL1R0
C594# ELECTROLYTIC CAP. 10µF/50V M or CE1JMASTL100
# ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C601# METALLIZED FILM CAP. 0.1µF/250V or CT2E104MS037
# FILM CAP.(MP) 0.1µF/250V K or CT2E104DC011
# METALLIZED FILM CAP. 0.1µF/275V K CT2E104HJE06
C605 CERAMIC CAP. F Z 0.01µF/500V or CCD2JZP0F103
CERAMIC CAP. 0.01µF/AC250V or CCD2EZA0F103
CERAMIC CAP. E Z 0.01µF/500V CCD2JZP0E103
C606 CERAMIC CAP. F Z 0.01µF/500V or CCD2JZP0F103
CERAMIC CAP. 0.01µF/AC250V or CCD2EZA0F103
CERAMIC CAP. E Z 0.01µF/500V CCD2JZP0E103
C609 CERAMIC CAP. B K 1000pF/2KV or CCD3DKD0B102
CERAMIC CAP. B K 1000pF/2KV or CCD3DKP0B102
CERAMIC CAP. B K 1000pF/2KV CA3D102MR030
C610# A ALMINIUM ELECTROLYTIC CAP150µF/
200V or
CA2D151NC088
# A ELECTROLYTIC CAPACIT0R 150µF/200V CA2D151S6012
C610# B ELECTROLYTIC CAP. 220µF/200V or CA2D221NC088
# B ELECTROLYTIC CAP. 220µF/200V SL X CA2D221S6003
C611 FILM CAP.(P) 0.068µF/50V J or CMA1JJS00683
FILM CAP.(P) 0.068µF/50V J CA1J683MS029
C612 CERAMIC CAP. LB 330pF/2KV or CA3D331KG004
CERAMIC CAP. BN 330pF/2KV or CCD3DKA0B331
CERAMIC CAP. 330pF/2KV or CA3D331PAN04
CERAMIC CAP. RB 330pF/2KV CA3D331TE006
C616 A FILM CAP.(P) 0.039µF/50V J or CMA1JJS00393
A FILM CAP.(P) 0.039µF/50V J CA1J393MS029
C616 B FILM CAP.(P) 0.056µF/50V J or CMA1JJS00563
B FILM CAP.(P) 0.056µF/50V J CA1J563MS029
C617 CERAMIC CAP.(AX) B K 330pF/50V CCA1JKT0B331
If C642 is 0.01µF, then C643 is 0.01µF.
C642# SAFETY CAP. 10000pF/250V or CCG2EMA0F103
# SAFETY CAP. F M 0.01µF/250V or CCG2EMP0F103
# CERAMIC CAP. 0.01µF F CS CCG2HMN0F103
C643# SAFETY CAP. 10000pF/250V or CCG2EMA0F103
# SAFETY CAP. F M 0.01µF/250V or CCG2EMP0F103
# CERAMIC CAP. 0.01µF F CS CCG2HMN0F103
If C643 is 4700pF, then JS642 (PCB JUMPER) is used.
C643# SAFETY CAP. 4700pF/250V KX CA2E472MR050
JS642 PCB JUMPER D0.6-P7.5 JW7.5T
C650 A CERAMIC CAP. LB 220pF/2KV or CA3D221KG004
A CERAMIC CAP. BN J 220pF/2KV or CCD3DKA0B221
A CERAMIC CAP. 220pF/2KV or CA3D221PAN04
A CERAMIC CAP. RB 220pF/2KV CA3D221TE006
C650 B CERAMIC CAP. LB 470pF/2KV or CA3D471KG004
B CERAMIC CAP. BN 470pF/2KV or CCD3DKA0B471
B CERAMIC CAP. 470pF/2KV or CA3D471PAN04
B CERAMIC CAP. RB 470pF/2KV CA3D471TE006
C651 B CERAMIC CAP. LB 470pF/2KV or CA3D471KG004
B CERAMIC CAP. BN 470pF/2KV or CCD3DKA0B471
B CERAMIC CAP. 470pF/2KV or CA3D471PAN04
B CERAMIC CAP. RB 470pF/2KV CA3D471TE006
C654# ELECTROLYTIC CAP. 1µF/50V M or CE1JMASTL1R0
# ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
# ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL010
Ref. No. Mark Description Part No.
