20031105 13-4 L2200EL
SWITCHING DIODE 1N4148 NDTZ001N4148
D661# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D662# ZENER DIODE MTZJT-776.8B or QDTB0MTZJ6R8
# ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D666 ZENER DIODE MTZJT-7736B or QDTB00MTZJ36
ZENER DIODE DZ-36BSBT265 NDTB00DZ36BS
D671# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D672 PCB JUMPER D0.6-P5.0 JW5.0T
D673 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D682# ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
# ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D691# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D694# PCB JUMPER D0.6-P5.0 JW5.0T
D811# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D831 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
ICS
IC31 IC:VIF/SIF DETECTOR M61111FP QSZBA0SMB010
IC111# IC M61271M8-058FP-71 QSZAA0RMB182
IC151 IC:MEMORY S524C20D21 or NSZBA0SSM028
IC:MEMORY BR24C02F-W or QSMBA0SRM003
IC:MEMORY BR24C02F or QSMMA0SRM003
IC:EEPROM CAT24WC02JI or NSZBA0SBG001
IC(EEP-ROM) M24C02-WMN6 NSZAA0SSS004
IC551# VERTICAL OUTPUT IC LA78040A QSBBA0SSY003
IC601# PHOTOCOUPLER PS2501-1W or QPEW0PS25011
# PHOTO COUPLER PS2501-1L or QPEL0PS25011
# PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
# PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
IC801 AUDIO AMP LA4224 QSZAA0SSY005
COILS
L1 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 22µH-K-5FT or LLARKBSTU220
INDUCTOR 22µH-K LLARKDQKA220
L32 INDUCTOR 15µH-J-26T LLAXJATTU150
L33 INDUCTOR 22µH-J-26T LLAXJATTU220
L51 INDUCTOR 100µH-K-5FT or LLARKBSTU101
INDUCTOR 100µH-K LLARKDQKA101
L111 PCB JUMPER D0.6-P5.0 JW5.0T
L301 INDUCTOR 100µH-K-5FT or LLARKBSTU101
INDUCTOR 100µH-K LLARKDQKA101
L341 PCB JUMPER D0.6-P5.0 JW5.0T
L342 PCB JUMPER D0.6-P5.0 JW5.0T
L601# LINE FILTER TLF12UA302W1R0 or LLBG00ZTU025
# LINE FILTER LF005 or LLBG00ZLH001
# LINE FILTER UU10.5-A or LLBG00ZY2008
# LINE FILTER SA-91213B or LLBG00ZSA002
# LINE FILTER 6.35MH UU10-002 LLBG00ZKV001
L692 CHOKE COIL 47µH-K LLBD00PKV007
TRANSISTORS
Q31 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q111 TRANSISTOR 2SC2785(F) or QQSF02SC2785
Ref. No. Mark Description Part No.
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q321# TRANSISTOR 2SC2785(F) or QQSF02SC2785
# TRANSISTOR KTC3199(GR) or NQS10KTC3199
# TRANSISTOR KTC3198(GR) or NQS40KTC3198
# TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q571# A TRANSISTOR TT2138LS-YB11 or QQZZ00TT2138
# A TRANSISTOR 2SC5884000RF QQZZ02SC5884
Q571# B TRANSISTOR TT2140LS-YB11 or QQZZ00TT2140
# B TRANSISTOR 2SC5885000RF QQZZ02SC5885
Q572 TRANSISTOR 2SC1627Y-TPE2 QQSY02SC1627
Q601# MOS FET 2SK2662 QF5Z02SK2662
Q601# A FET 2SK3543 QFWZ02SK3543
Q601# B MOS FET 2SK3563 QFWZ02SK3563
Q602# TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
# TRANSISTOR 2SC2120-Y(TPE2) QQSY02SC2120
Q662# TRANSISTOR 2SC2785(F) or QQSF02SC2785
# TRANSISTOR KTC3199(GR) or NQS10KTC3199
# TRANSISTOR KTC3198(GR) or NQS40KTC3198
# TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q671# TRANSISTOR 2SA1175(F) or QQSF02SA1175
# TRANSISTOR KTA1267(GR) or NQS10KTA1267
# TRANSISTOR KTA1266(GR) or NQS40KTA1266
# TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q675 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q676 RES. BUILT-IN TRANSISTOR BA1F4M-T
or
QQSZ00BA1F4M
RES. BUILT-IN TRANSISTOR KRC103M NQSZ0KRC103M
Q681 TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
TRANSISTOR 2SC2120-Y(TPE2) or QQSY02SC2120
TRANSISTOR KTC3203(Y) NQSY0KTC3203
Q682 TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
TRANSISTOR 2SC2120-Y(TPE2) or QQSY02SC2120
TRANSISTOR KTC3203(Y) NQSY0KTC3203
Q683 TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
TRANSISTOR 2SC2120-Y(TPE2) or QQSY02SC2120
TRANSISTOR KTC3203(Y) NQSY0KTC3203
RESISTORS
R3 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R4 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R5 CHIP RES.(1608) 1/10W J 100 Ω RRXAJB5Z0101
R31 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJB5Z0222
R32 CHIP RES.(1608) 1/10W J 390 Ω RRXAJB5Z0391
R33 CHIP RES.(1608) 1/10W J 270 Ω RRXAJB5Z0271
R34 CHIP RES.(1608) 1/10W J 220 Ω RRXAJB5Z0221
R36 CHIP RES.(1608) 1/10W J 10k Ω RRXAJB5Z0103
R37 CHIP RES.(1608) 1/10W J 220 Ω RRXAJB5Z0221
R38 CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJB5Z0332
R39 CHIP RES.(1608) 1/10W J 27k Ω RRXAJB5Z0273
R41 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJB5Z0682
R43 CHIP RES.(1608) 1/10W J 12k Ω RRXAJB5Z0123
R45 CHIP RES.(1608) 1/10W J 22k Ω RRXAJB5Z0223
R51 CHIP RES.(1608) 1/10W J 220k Ω RRXAJB5Z0224
R52 CHIP RES.(1608) 1/10W J 220k Ω RRXAJB5Z0224
R102 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJB5Z0222
R103 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJB5Z0182
R104 CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJB5Z0332
Ref. No. Mark Description Part No.
