20031105 13-7 L2200EL
CRT CBA
# A FLYBACK TRANS FNI14A001 LTF00CPSM018
T571# B FLYBACK TRANSFORMER JF0501-3201
or
LTF00CPXB044
# B FLYBACK TRANS BSC23-2631S or LTF00CPS2060
# B FLYBACK TRANS BSC25-0243 or LTF00CPP1008
# B FLYBACK TRANS FNI20A001 LTF00CPSM019
T572 A H0RIZONTAL DRIVE TRANS LP2-005 or LTH00CPA5005
A HORIZONTAL DRAIVE TRANS CSA-
LF051
LTH00CPSA005
T572 B H0RIZONTAL DRIVE TRANS LP2-004 or LTH00CPA5004
B HORIZONTAL DRAIVE TRANS CSA-
LF049
LTH00CPSA004
T601# A SWITCHING TRANS 02Y0438 or LTT00CPKT099
# A SWITCHING TRANS CSA-SW0240A LTT00CPSA143
T601# B SWITCHING TRANS KD-01743 or LTT00CPKT088
# B SWITCHING TRANS CSA-SW0049 LTT00CPSA122
TP300 PCB JUMPER D0.6-P12.5 JW12.5T
TP601 PCB JUMPER D0.6-P10.0 JW10.0T
TU1 TUNER UNIT TEQH9-001A UTUNNTUAL032
VR661# A CARBON P.O.T. 30k Ω B or VRCB303KA011
# A CARBON P.O.T. 30k Ω B VRCB303HH014
VR661# B CARBON P.O.T. 50k Ω B or VRCB503KA011
# B CARBON P.O.T. 50k Ω B VRCB503HH014
X301 X'TAL 3.579545 MHz or FXD355LLN003
X'TAL 3.579545MHz(30PPM) FXD355LCHE01
Ref. No. Mark Description Part No.
CRT CBA
Consists of the following
------------
CAPACITORS
C501 A CHIP CERAMIC CAP. CH J 270pF/50V CHD1JJBCH271
C501 B CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJBCH331
C502 CHIP CERAMIC CAP. CH J 270pF/50V CHD1JJBCH271
C503 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJBCH331
C504 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASTL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C510 CERAMIC CAP. B K 1000pF/2KV or CCD3DKD0B102
CERAMIC CAP. B K 1000pF/2KV or CCD3DKP0B102
CERAMIC CAP. B K 1000pF/2KV CA3D102MR030
CONNECTOR
CN501 PIN CONNECTOR 005P-5100 JTEA001TG001
COILS
L501 A INDUCTOR 150µH-J-5FT or LLARJCSTU151
A INDUCTOR 150µH-K-5FT LLARKDSKA151
L501 B INDUCTOR 180µH-J-5FT or LLARJCSTU181
B INDUCTOR 180µH-K-5FT LLARKDSKA181
TRANSISTORS
Q501 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Q502 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Q503 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Ref. No. Mark Description Part No.
RESISTORS
R501 METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R502 METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R503 METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R504 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R505 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R506 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R509 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R511 CHIP RES.(1608) 1/10W J 33 Ω RRXAJB5Z0330
R512 CHIP RES.(1608) 1/10W J 33 Ω RRXAJB5Z0330
R513 CHIP RES.(1608) 1/10W J 33 Ω RRXAJB5Z0330
R514 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R515 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R516 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R517 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R518 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R519 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R521 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R522 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R523 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R537 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R538 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
MISCELLANEOUS
BC501 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
CLN501 A PARALLEL WIRE L=250 3P WX1L1000-102
CLN501 B PARALLEL WIRE 3P WX1L1114-101
JK501# CRT SOCKET ISMS02S JSCC220PK003
Ref. No. Mark Description Part No.
To Next Page
