Synca MR320 - Backrest Heat Function Problems

3.5 Heat function issue – Backrest pad
Replace the main board ( Diagram-M M3)
Unzip the backrest pad(Figure A) ,check
the connector (Figure B),
Does the connector of the heater surely
connected?
Replace heater ()
Yes
No
Are the both sides heater abnormal?
Replace the main board ( Diagram-
M M3)
No
No
Figure A
Figure B
Figure C
Hint: Connect a new heater, can find
out the problem easily
