5.Exploded diagram
Level Parent PN Item NO. JHT Parts No. SAP Parts No. Description
1 PZMR337-1US 2A 1000412179 1000412179 Remote controller assembly
1 PZMR337-1US 3B 1000412201 1000412201 filter PCB
1 PZMR337-1US 4B 1000412223 1000412223 adapter PCB
1 PZMR337-1US 4E 1000412224 1000412224 air pump
1 PZMR337-1US 6E 1000412225 1000412225 main PCB
1 PZMR337-1US 7E 1000412227 1000412227 air valve
