- 1 -
1.0 Technical Specifications
1.1 Specifications
512K RAM, Battery backed.
Magnetic Stripe (track 1, 2, or 3) – Optional
Bar Code (0-of-9, 2-of-5, 128)
Proximity Reader (HID 26 Bit) – Optional
Fingerprint (1:1 validation 1:N identification) – Optional
2x16 LCD backlit Alphanumeric with Decimal point
ASCII-based, Over Communication Port
Standard: RS-232 Port - Bi-directional Local Communications
Standard: RS-485 Port
Optional: 14.4 Baud Modem
Optional: 10/100 Ethernet
Voltage: 110/230 Vac + 10%, 100mA
Operating Temperature -20
o
-60
o
C
Humidity: up to 95% RH
1.2 Available Options
Ethernet Communications:
With the optional internal Ethernet card, the terminal can be connected to any 10/100
Ethernet network.
Wi-Fi (Wireless) Communications:
The TA-785’s wireless card allows the 745 to communicate over a standard
802.11b network. The wireless network must be configured with an IP address, gateway, subnet, and WEP key (if
available).
P.O.E. (Power over Ethernet:
The TA-785’s has the optional capability of drawing its power from the Ethernet
communications line. This eliminates the need for high voltage power at the terminal locations. Note: The Ethernet
Network must support POE communications.
Biometric Fingerprint Reader:
The TA-785 can store up to 9,090 fingerprint templates for biometric verification (1 to 1)
or identification (1 too many). The terminal utilizes a high resolution 500 dpi finger template.
The TA-785 has two reader ports to connect external devices such as a Bar code Gun or an
Access Control Swipe Reader that could be mounted outside a door.
The TA-785
is constructed of injection molded plastic, which, pound for pound is stronger than steel, yet lightweight
and attractive. The terminals have recessed membrane keypads, which create a watertight seal against external
elements.
