How to Install
Below Counter Installation Procedure
Warning!
Keep order of Dust pre-Filter
and Constant ow valve
when machine is installed
Dust Pre Filter
Source water
Source water
Dust Pre Filter
inlet
inlet
Cold water valve
Above Counter Installation Procedure
Diverter valve
