15
2
Connect 1/4” hose to the “T” adapter
in "Figure 2"
3
Push in and fasten the 1/4” hose
in "Figure 2" into the water
inlet at the bottom of the machine.
4
After finishing the connection of
"Figure 4" open the water supply
valve and adjust the water pressure.
5
Check for leaks on the connections
part after installation completed.
Below Counter Installation Procedure
Install after stop water supply.
Caution
1
Loosen the nut of the cold water
valve.
[Figure 4]
[Figure 1]
[Figure 3]
[Figure 5]
[Figure 2]
inlet
Cold water valve
1/4” Hose
“T”adapter
To Next Page
