The unique index of each number manipulation rule, which denotes its priority. A
number manipulation rule with a smaller index value has a higher priority. If a call
matches several number manipulation rules, it will be processed according to the
one with the highest priority.
More information about each number manipulation rule, with the default value of
default.
IP address from where the call is initiated. This item can be set to a specific IP
address or “*” which indicates any IP address.
CallerID Prefix,
CalleeID Prefix
A string of characters at the beginning of the caller/called party number. It can be a
specific string consisting of digits 0~9, ”[*]”, ”#" or character ranges defined by [ ]. ‘[ ]’
represents a character within the range it defines. Values in [ ] only can be digits
‘0~9’, “[*]”, ”#", punctuations ‘-‘ and ‘,’. (’-’ is used between two characters to
indicates any character between these two characters. ’,’ is used to separate
characters or character ranges, representing alternatives.) For example, 057[1-3,6]
represents the string 0571, 0572, 0573 or 0576. Also these items can be set to “*”
which indicates any string. These two configuration items together with Call
Initiator specify a number manipulation rule for calls.
Note: “[*]” represents DTFM symbol *, while “*” represents any string; Multiple
CallerID/CalleeID prefixes can be added simultaneously. They are separated by “:”.
Stripped Digits from
Left
The amount of digits to be deleted from the left end of the number. If the value of
this item exceeds the length of the current number, the whole number will be
deleted.
Stripped Digits from
Right
The amount of digits to be deleted from the right end of the number. If the value of
this item exceeds the length of the current number, the whole number will be
deleted.
Reserved Digits
from Right
The amount of digits to be reserved from the right end of the number. Only when the
value of this item is less than the length of the current number will some digits be
deleted from left; otherwise, the number will not be manipulated.
Designated information to be added to the left end of the current number.
Designated information to be added to the right end of the current number.
Note: The number manipulation is performed in 5 steps by the order of the following
configuration items: Stripped Digits from Left, Stripped Digits from Right, Reserved Digits
from Right, Prefix to Add and Suffix to Add.
After configuration, click Save to save the settings into the gateway or click Close to cancel the
settings. See the figure below.
Figure 3-42 IPTel/IP CallerID Manipulation Interface (Standard)
Click Modify in Figure 3-42 to modify a number manipulation rule. The configuration items on the
IPTel/IP CallerID manipulation rule modification interface are the same as those on the Add
