16
Manual Shutter Control : 1/60(1/50), 1/100(1/120), 1/250,
1/500, 1/1000, 1/2000, 1/4000,
1/10,000(Dip Switch)
Flickerless(F.F) : ON/OFF (Dip Switch)
BLC : ON/OFF (Dip Switch)
EI : ON/OFF (Dip Switch)
Auto Iris Lens : DC/Video (Dip Switch)
AGC Select : Normal/High (Dip Switch)
AGC : ON/OFF (Dip Switch)
White Balance : ON/OFF (Dip Switch)
Auto, Quick, Indoor, Outdoor
Sync : Internal / Line Lock (Dip Switch)
Vert Phase Adjust : Adjustable (POT)
DC Iris Level Adjust : Adjustable (POT)
Connector and Mechanical
Video Output : BNC Connector
Power Input : 3-pin Terminal Block
AI/DC Output : 4-pin mini din jack (Standard
Connection)
Lens Mount : C/CS (Selected through back
focus)
Mounting Hole : 1/4" UNC Top and Bottom
External Dimensions : 2.4W x 2.1H x 5.0D inch
(62W x 54H x 127D mm)
Weight : 9.34oz (265g)
DSP COLOR CAMERA
1/3” INTERLINE TRANSFER CCD
STANDARD RESOLUTION
HIGH RESOLUTION
50301598D
