6
Installation of the camera must be performed by qualified service
personnel in accordance with all local and national electrical and
mechanical codes.
Carefully remove the color camera and its accessories from the carton
and verify that they were not damaged in shipment.
The contents of the package includes:
1. Color CCD camera
2. Mini-DIN connector (for video-or dc-type auto-iris lens)
MANUAL IRIS LENS ADJUSTMENT
When using a manual iris lens, turn the iris ring on the lens to the OPEN
position and adjust the manual iris for the appropriate range. Adjust
during the brightest conditions, opening the lens to the minimum f-stop
yielding a good picture under the brightest scene conditions. Do not
saturate the picture.
The manual iris is used in indoor applications where lighting from
windows can considerably affect the light level of the room.
VIDEO AUTO IRIS
INSTALLATION & ADJUSTMENT
The camera supports video-type auto iris lenses which adjust to
changing light levels. Perform the following steps to install and adjust a
video-type auto iris lens.
1. If necessary, solder the lens control wires to the connector supplied
with the camera.
