5 Operation
5.1 Switching the device on
Fig. 20: ON/OFF button for switching on and off
Press the ON/OFF button between the dummy plugs on the left-
hand side of the WAVE 221 PC.
ð
The system goes into operation.
5.2 Switching the device off
NOTICE!
Loss of data due to failure to save it.
Failure to save your data or failure to close down the
industrial PC in an orderly fashion may cause you to lose
data and may also damage the components.
– Save your data regularly.
– Always close down the industrial PC in an orderly
fashion.
Close the system down in an orderly fashion.
ð
The system is switched off.
The system cannot be closed down in an orderly fashion.
Hold the ON/OFF button pressed for about five seconds.
ð
The system is switched off.
5.3 Operating the touchscreen
With PCT (projected capacitive) multi-touch there is no need
to install a driver.
Install the installation files on the supplied USB stick.
Installing the driver
Windows XP
Operation
Operating the touchscreen
WAVE 221 PC - Industrial PC
25
