TFSR EC/TFSK EC
TFSR EC/
TFSK EC 160
(10,0V)
TFSR EC/
TFSK EC 200
(10,0V)
Fig 5
0
10
1=Min
5
0 0.05 0.1 0.15 0.2
0
200
400
600
800
[m³/s]
[Pa]
0 200 400 600
[m³/h]
8471/8472
2,4V
4,9V
7,2V 10V
TFSR EC/TFSK EC 160
0
10
1=Min
5
0 0.1 0.2 0.3
0
100
200
300
400
500
[m³/s]
[Pa]
0 200 400 600 800 1000
[m³/h]
8376/8529
5V
6V
7V
10V
TFSR EC/TFSK EC 200
