SystemAir K EC Series

25
206268 Systemair Sverige AB
KV DUO 400 EC
(10,0V)
KV DUO 500 EC
(10,0V)
Fig 15
0
10
1=Min
5
0 0.4 0.8 1.2 1.6
0
250
500
750
1000
Q [m³/s ]
Ps [Pa]
0 1000 2000 3000 4000 5000
[m³/h ]
17007, 17006
4,6V 7V 10V
KV DUO 400 EC
2,3V
0
10
1=Min
5
0 0.5 1 1.5 2
0
300
600
900
1200
Q [m³/s ]
Ps [Pa]
0 2000 4000 6000
[m³/h ]
17015, 17016
6,1V4,3V 10V
KV DUO 500 EC
2,2V
