SystemAir K EC Series

6
206268 Systemair Sverige AB
For RS 50-25 EC
For RS 60-35 EC, RSI 60-35 EC
N
L
123
45
-
0
10
5
1=Min
+
Blue Blue Red White 1 White 2 Black Yellow/green Yellow
LN12345678
Yellow/green Black Blue Blue Yellow Red Brown White 1 White 2 White
-
010
5
1=Min
+
1
Alarm NC
2
Alarm COM
3
GND
4
Control input 0-10 VDC
5
Output 10 VDC max 10 mA
6
7
Interface for Modbus, RSB
8
Interface for Modbus, RSA
1
GND
2
Control input 0-10 VDC
3
Output 10 VDC max 10 mA
4
Alarm NC
5
Alarm COM
