4
| Unloading from trailer
4.2 Using lifting frame
Warning
• Secure the lifting straps on the lifting bars.
• Do not compress the air handling unit's chassi with the lifting straps.
Use a lifting frame connected to lifting bars in the air handling unit's feet.
For size Topvex SC20-Topvex SC35, Topvex TC20–Topvex TC35, place the lifting bars in the outer feet of the air han-
dling unit.
Topvex SC60, Topvex SC70, Topvex TC60, Topvex TC70 are placed in sections on a pallet. Use lifting frame to lift section
by section. Place the lifting bars in the feet.
Attach the lifting straps to the lifting bars.
214958 | A007
