Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
Pressure
controlEAF
Setp1/1:250
Pa
Setp1/2:100
Pa
Settheexternalpressureset
pointfornormalspeed(1/1)
andreducedspeed(1/2)forthe
supplyairfan.
Outdoor
comp.Setp.1
—20°C=0Pa
10°C=0Pa
Act.Comp:0
Pa
SettheEAFpressure
compensationforthesettable
outdoortemperature.The
outdoorcompensationislinear
andissetusingtwoparameter
pairswhichgivethevalueofthe
compensationattwodifferent
outdoortemperatures.The
compensationcanbepositive
ornegative.
Showstheactualpressure
compensation.
→Timesettings
→Time/Date
Setcorrecttimeanddate.
→TimerNormal
Speed
NormalSpeed
Monday
Per1:
07:00–16:00
Per2:
00:00–00:00→
NormalSpeed
Monday-Friday
Per1:
07:00–16:00
Per2:
00:00–00:00
SetweekscheduleMonday
toSunday,Monday-Friday+
Holidayfornormalspeed.
Possibletoset2periodsper
day.
00:0024:00forcontinuous
running.00:0000:00
inactivatestheperiod.
Notethesettingsinthe
commissioningrecord.
→TimerReduced
Speed
Reducedspeed
Monday
Per1:
00:00–24:00
Per2:
00:00–00:00→
ReducedSpeed
Monday-Friday
Per1:
00:00–24:00
Per2:
00:00–00:00
SetweekscheduleMonday
toSunday,Monday-Friday+
Holidayforreducedspeed.
Possibletoset2periodsper
day.
00:0024:00forcontinuous
running.00:0000:00
inactivatestheperiod.
Notethesettingsinthe
commissioningrecord.
TopvexSR/TR03,SR/TR04,SR/TR06OperationandMaintenanceInstructions
206902
14
SystemairAB
