Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
→Extended
running
Extended
running
60min
Timeinext.
running
0min
Setthetimeforextended
running.Usedigitalinputto
forcetheunittostartorincrease
tonormalrunningalthoughthe
timersaystherunningmode
shouldbeOfforReduced.
Iftherunningtimeissetto0
theunitonlyrunsaslongasthe
digitalinputisclosed.
Thetimetheextendedrunning
isactiveismonitoredin"Time
inext.Running".
It'salsopossibletosetatime
hereaswellinordertoshorten
theinitialsetperiod.
→HolidaysHolidays
(mm:dd)
1:01–01—01–02
2:09–04—09–10
3:01–05—01–05
Setupto24separatepossible
holidayperiodsforafullyear.
Aholidayperiodcanbeany
numberofconsecutivedays
fromoneandupwards.
Thedatesareintheformat:
MM:DD.
Whenthecurrentdatefalls
withinaholidayperiod,the
schedulerwillusethesettings
fortheweekday“Holiday”.
→Manual/Auto
Inthismenutherunningmode
ofalltheconguredoutput
signalsandanumberofcontrol
functionscanbemanually
controlled.
Thesupplyaircontroller's
outputsignalcanbemanually
set(Manual/Auto)toany
valuebetween0and100%.
Thetemperatureoutputsignals
willchangeaccordinglyifthey
areinAutomode.Itisalso
possibletomanuallycontrol
eachofthetemperatureoutput
signalsindividually.
Sinceleavinganyofthe
outputsinmanualcontrolwill
disruptthenormalcontrol,
analarmwillbegeneratedas
soonasanyoutputissettoa
manualmode.
TopvexSR/TR03,SR/TR04,SR/TR06OperationandMaintenanceInstructions
206902
15
SystemairAB
