SystemAir Topvex TR20 User Manual

Product information |
1
1 Product information
This manual includes the information required for installing the heat recovery unit type Topvex SR, TR manufactured by
Systemair Sverige AB. The units include the following model options:
The air handling units is delivered with airflow control CAV (Constant Air Volume).
Side connected units:
Topvex SR20, Topvex SR25, Topvex SR35, Topvex SR60, Topvex SR70
Weather protection and built-in control cabinet (ODK)
Top connected units:
Topvex TR20, Topvex TR25, Topvex TR35, Topvex TR60, Topvex TR70, Topvex TR80
Options:
The air handling units are delivered with the electrical cabinet and supply air intake on right (R) or left (L) side.
Heater options are electrical (EL), hot water (HW) or none (None).
Defrosting options are bypass defrosting (B) or section defrosting (S).
Fan impeller options are composite (standard) or aluminium (M0).
EL heater options kW:
SR/TR20
1,4 5,2
SR/TR25
1,4 5,2
SR/TR35
3,5 7,1
SR/TR60
3,5 7,1 10,4
SR/TR70
3,5 10,4 14,2
TR80 7,1 14,2 28,3
HW heater options:
HWH (High power) or HWL (Low power)
Type designation example Topvex TR60 HWH-L
Topvex TR 60 HWH -L
Unit name
Top connected
Size
Hot water
heater (High)
Left hand unit
254050 | A001
