SystemAir Topvex TR800 User Manual

Topvex TR800, TR1300, TR1800, TR4000
Operation and Maintenance Instructions
Systemair Inc.
16
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Outdoor
comp.Setp. 1
-4°F = 0 in.wg
50°F = 0 in.wg
Act. Comp: 0
in.wg
Set the SAF pressure
compensation for the settable
outdoor temperature. The
outdoor compensation is linear
and is set using two parameter
pairs which give the value of the
compensation at two different
outdoor temperatures. The
compensation can be positive or
negative.
Shows the actual pressure
compensation.
Pressure
control EAF
Actual: in.wg
Setp.: in.wg
Shows the actual external
pressure and set point for the
extract air fan.
Only visible if the unit is
congured for “Pressure
control: (VAV)
Pressure
control EAF
Setp 1/1: 1.0
in.wg
Setp 1/2: 0.4
in.wg
Set the external pressure set
point for normal speed (1/1)
and reduced speed (1/2) for the
supply air fan.
Outdoor
comp.Setp. 1
-4°F = 0 in.wg
50°F = 0 in.wg
Act. Comp: 0
in.wg
Set the EAF pressure
compensation for the settable
outdoor temperature. The
outdoor compensation is linear
and is set using two parameter
pairs which give the value of the
compensation at two different
outdoor temperatures. The
compensation can be positive or
negative.
Shows The actual pressure
compensation.
→ Time settings → Time/Date
Set correct time and date.
→ Timer normal
speed
Set week schedule Monday to
Sunday + Holiday for normal
speed. Possible to set 2 periods
per day.
00:00 24:00 for continuous
running. 00:00 00:00 inactivates
the period.
Note the settings in the
commissioning record
→ Timer reduced
speed
Set week schedule Monday to
Sunday + Holiday for reduced
speed. Possible to set 2 periods
per day.
00:00 24:00 for continuous
running. 00:00 00:00 inactivates
the period.
Note the settings in the
commissioning record
