Taarup 4036C - Lubrication

55
Machines with swivel hitch Machines with wide angle shaft standard drawbar
Every 10 hours
(
daily)
Every 20 hours Every 40 hours Numbers of lubrication point
*)
XX
5
PTO shaft: tractor - swivel hitch
7
PTO shaft: tractor - wide angle shaft
*)
XX
7
PTO shaft below drawbar
X
1
Mounting frame
X
1
Chain coupling or universal joint
XX
1
Bearing, intermediate shaft
XX
1
Drawbar bearing
XX
2
Cutterbar suspension
*)
X
7
Models 4028C - 4032C - 4036C:
PTO shaft, transverse
*)
XX
Lubrication (Lubricants, - see page 77)
Before starting up new machine: Check the oil level of the gearbox and cutterbar, - see pages 59
and 61. Lubricate the whole machine and P.T.O. shafts.
*) All universal joints and bearings of the P.T.O. protection tubes must be lubricated after every 8
- 10 hours use. Use Graphite or Molybdenum grease.
The P.T.O./drive shafts must be checked regularly. If the profile tube is damaged or
lacks lubrication, the telescopic force might become excessive and so cause damage
to the P.T.O. shaft on the tractor or machine.
- table continued on next page.
