Tab Silverball Cosmo - Detailed Diagrams, Spare Parts, and Wiring

Detailed drawing Silverball Cosmo
Lower housing section:
Page 41
1. Metal body, Cosmo 022.082-006
2. Stop bolt with counter nut, DIN 439 022.011-603
3. Fan cover, Cosmo 022.082-038
4. Fan plate 464.126-127
5. Combination surge protector 671.115-507
6. Soft housing feet 022.011-400
7. PC TAB Micro-ATX Cosmo 831.000-017
8. Plastic side, left, Cosmo 210.075-027
1
3
4
5
8
7
6
2
